Waterproof Mini Sc/Pdlc/Odva/Odc/Aarc/Fullaxs Connectors Compatible with Field Tactical YG for Indoor Outdoor Use 4G/3G Network
Product Details
| Product Name | Waterproof Fast Connector | Type | Huawei Type |
|---|---|---|---|
| Cable Type | Flat Drop Cable 3.0mm,5.0mm, Flat 2.0*3.0mm | No. Of Fiber | 1 Core |
| IP Level | IP65 | Feature | Compatible With ESC250D, Sumitomo, FJK, Furukawa Fast Connector |
| Application | FTTH FTTB FTTX Network | OEM | Welcome |
| Highlight | Waterproof Mini SC fiber optic connectors,PDLC fiber optic connectors for 4G network,Field tactical YG compatible fiber connectors |
||
Product Description
SC/APC Huawei Type Mini-SC Waterproof Fast Connector Reinforced Fiber Optic Connector quick connect
Product Description
Field assembly optical reinforced adapter provide an cost effective, easy, environmental seal and mechanical protection for 1 fibers simplex SC style connections. Inside cover can protect ferrule end face far away scratch when mating with receptacle; Special fool-proofing design equal to HUAWEI Mini SC connector has blind-mating function; One hand Bayonet-style mechanical latch. The assemblies guarantee an easy, one-step connection system with the combined push-pull insertion and bayonet-style mechanical latch. It provides quick installation solutions and has good performance on mating receptacle / Adapter.
Cable can be armoured or non-amoured. The industrial panel-mount, plastic adapters serve as a sealed feed-through for the fiber connection. The new industrial integrated flange-mount adapters are designed for tight, side-by-side applications.
Feature
- Compact size,easy to operate,durable.
- Easy connection to hardended adapters on terminals or closures.
- Reduce welding,connect directly to achieve interconnection.
- IP68 water and dust protection.(1M,1 hour)
- Spiral clamping mechanism ensures long-term reliable connection.
- Guide mechanism,can be blinded with one hand,simple and quick,connect and install.
- Low operating temperature: - 10 ℃ ~ + 70 ℃
- Accepts 2.*3.0mm,3.0mm ,5.0mm Cable Diameters
- Factory or field installation,Allows flexibilityto use factory terminated and tested assemblies or retrofit to pre-terminated or field installed assemblies.
Applications
- Fiber optic communications in harsh outdoor environments.
- Outdoor communications equipment connection.
- Waterproof fiber equipment SC port.
- Remote wireless base station.
- FTTX wiring projiect.
| Cable Scope | 2*3.0mm flat drop cable, |
|---|---|
| Fiber Diameter | 125μm ( 652 & 657 ) |
| Coating Diameter | 250μm |
| Mode | SM |
| Operation Time | about 15s(exclude fiber presetting) |
| Insertion Loss | ≤ 0.3dB(1310nm & 1550nm) |
| Return Loss | ≥ 50dB for UPC, ≥ 55dB for APC |
| Success Rate | >98% |
| Reusable Times | >5 times |
| Tensile Strength | >30 N |
| Temperature | -40 ~ +85 C |
| On-line Tensile Strength Test (20 N) | IL ≤ 0.3dB |
| Mechanical Durability(500 times) | IL ≤ 0.3dB |
| Drop Test(4m concrete floor, once each direction, three times total) | IL ≤ 0.3dB |
