AS-ONU49 4GE+1VOIP+AX1800 WIFI6 XPON ONU

  • AS-ONU49 4GE+1VOIP+AX1800 WIFI6 XPON ONU
  • AS-ONU49 4GE+1VOIP+AX1800 WIFI6 XPON ONU
  • AS-ONU49 4GE+1VOIP+AX1800 WIFI6 XPON ONU
  • AS-ONU49 4GE+1VOIP+AX1800 WIFI6 XPON ONU
Place of Origin ZHEJIANG, CHINA
Brand Name ANSHI
Certification ISO9001, SGS
Model Number AS-ONU49
Minimum Order Quantity Negotiable
Price Negotiable

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name 4GE LAN +1 VOIP 1800M WIFI6 XPON ONU Optical Signal Access 1*GPON/EPON
Size 205*140*30mm Indicator Light POWER/PON/LOS/LAN1/LAN2/LAN3/LAN4/TEL1/USB 2.4G/5G/WPS
Weight 300g Power Adapter Input 100V～240V AC，50Hz～60Hz
PowerSupply Requirement 12V DC，1.5A Power Consumption <10w
Working Temperature -10°C ~ +45°C Environment Humidity 5% ~ 95% (Non-condensing)
Module Type Class B+ SC/UPC Interface Type 4*RJ45
Highlight

AS-ONU49 XPON ONU

,

AX1800 WIFI6 XPON ONU

,

4GE XPON ONU
Leave a Message
Product Description

AS-ONU49 4GE+1VOIP+AX1800 WIFI6 XPON ONU



Product Overview

AS-ONU49 model ONU is a user terminal device independently developed in line with such industrial background.The device has built-in two-layer switching function and three-layer routing function. With compact structure and small appearance, it is a kind of FTTH optical network unit with high performance and low power consumption, which is very suitable for the application requirements of various data services in FTTH networking scenarios of various operators.AS-ONU49 is an XPON product that can be adapted to EPON and GPON networks without replacing equipment and firmware.



Features

♦ Support EPON/GPON mode and switch mode automatically

♦ GPON:Compliance with IEEE 802.3ah & itu-t g.984.x standard
♦ GPON:8 T-CONTs,32 GEM Ports
♦ Integrate OMCI(GPON)/OAM(EPON) and TR-069 remote configuration and maintenance
♦ Layer 3 Home Gateway/CPE features with Hardware NAT, support Multiple WAN, Route/Bridge mode, etc
♦ Layer 2 Switching, support 802.1Q VLAN, 802.1P QOS, Bandwidth Control, Spanning Tree, etc
♦ Bi-directional FEC
♦ Support firewall level Settings, support based on URL/MAC/ IP/ address frame filtering
♦ Support multicast IGMP v2 proxy/ snooping, support MLD proxy/ snooping
♦ Qos supports PQ, WRR, and CAR queue scheduling
♦ Provide Maximum rate 1775Mbps Wireless interface, 2T2R external antenna, support multiple SSID Settings
♦ Support DDSN, ALG, DMZ and UPNP
♦ Provide POTS interface, support SIP protocol,POTS integrated circuit test complies GR-909

Highlights
♦ Dual band Wi-Fi, Superior performance of Wireless 11n and 11ac Transmission
♦ Compatible with 95% Third-party OLTs (Including Huawei/ZTE/Fiberhome/BT-PON and so on)
♦ Spport EPON/GPON mode and switch mode automatically
♦ Support Route PPPoE/DHCP/Static IP and Bridge mode
♦ Support ONU auto-discovery/Link detection/remote upgrade of software
♦ Support IPv4/IPv6 dual mode
♦ Support Firewall function and IGMP multicast feature
♦ Support LAN IP and DHCP Server configuration
♦ Support Port Forwarding and Loop-Detect






AS-ONU49 4GE+1VOIP+AX1800 WIFI6 XPON ONU 0AS-ONU49 4GE+1VOIP+AX1800 WIFI6 XPON ONU 1
