10 Pairs Metal Distribution Box With Earthing System with LSA Profile Module

10 Pairs Metal Distribution Box with earthing system with LSA Profile Module


Specifications:

1.Environment condition: -5-40 degree Celsius ;Relative humidity <85% (+30 degree Celsius);Atmospheric pressure: 70-106KPa ;
2.The modules are compatible with KRONE LSA-PLUS modules.
3.The design of contacts basing on the principle of airtight contacting makes a completely reliable connection between the contacts and wires
4.Pulling-out force: tin bronze and silver plating (20-40 uinch), pulling-out force not less than 25N
5.Internal diameter of connection wire: 0.4-0.6 mm
6.The performance of anti-burn: PBT (UL94V-0)or anti-burn ABS (UL94V-0),Combustibility achieved GB/T 5169.7-1985 standard

7.Insulated resistance: under standard atmospheric pressure ,Insulated resistance no less than 1,000M ohm between the two disjunct connections
8.Intermediate resistance between the reed terminators: no more than 7m ohm between intermediate reed under the standard examination condition
9.Intermediate resistance: no more than 3m ohm under standard examination condition
10.Dielectric strength: according to industry standard
11.Specification:60-100 pairs,Waterless,every specification has connection or disconnection types
12.Life: durability 200 cycles
