10 Pairs Disconnection Krone Type Connection Module LSA PLUS Krone NT Module , Back Mounting Frame

10 Pairs Disconnection Krone Type Connection Module LSA PLUS Krone NT Module , Back Mounting Frame

  • 10 Pairs Disconnection Krone Type Connection Module LSA PLUS Krone NT Module , Back Mounting Frame
  • 10 Pairs Disconnection Krone Type Connection Module LSA PLUS Krone NT Module , Back Mounting Frame
10 Pairs Disconnection Krone Type Connection Module LSA PLUS Krone NT Module , Back Mounting Frame
Product Details:
Place of Origin: ZHEJIANG, CHINA
Brand Name: ANSHI
Certification: ISO9001, CNACL, SGS, DAS
Model Number: XL-011NT
Payment & Shipping Terms:
Minimum Order Quantity: 100 pcs
Price: Negotiable
Packaging Details: CARTON:53*24*24CM
Supply Ability: 10000 pcs per week
Contact Now
Detailed Product Description
Material: ABS(94 V0) Or PBT Color: White/Grey
Contact: Iron, Brass Or Bronze Type: NT Module
Installation: Back&profile Mount Application: Cabling
High Light:

krone connection module

,

krone disconnection module

10 Pairs Disconnection Krone Type Connection Module LSA PLUS Krone NT Module, Back Mounting Frame



Technique Characteristics:



The disconnection type CT module have provision of testing the electrical parameters of the exchange and distribution sides by insertion of test plug without actually disconnecting the jumper wire or the cable from the termination module.



The module housing material we mainly offer with imported GE PBT and ABS(UL94V-0).Both material we will use new rall material but not recycling material(first recycling or second recycling).So we can offer good performance modules.You can get very cheap products in the market but they are mainly made of such recycling material PBT or ABS.



Mechanical Performance Insertion force : 40~75N
Pull Out Force : F≥25N(axial) F≥7.5N(radial)
IDC Life : 200 times(20-26 AWG Solid wire) minimum
Copper Conductor Diameter: Φ0.4~Φ0.8(mm)
Environment Characteristic Storage Tempreture: 40 to 70°C
Operating Temperature : 10 to 60°C
Relative Humidity: 95%, noncondition
Electrical Performance Insulation resistance: 1000 Mohms minimum
Contact resistance:7 mohms maximum

Dielectric intensity: AC 1000 Vrms 50Hz or 60Hz in 60s







10 Pairs Disconnection Krone Type Connection Module LSA PLUS Krone NT Module , Back Mounting Frame 0
