Wall Mount Telephone DP Box 10 Pairs Indoor Distribution Box With 10 Pair LSA Module

Wall Mount Telephone DP Box 10 Pairs Indoor Distribution Box With 10 Pair LSA Module

    • Wall Mount Telephone DP Box 10 Pairs Indoor Distribution Box With 10 Pair LSA Module
    • Wall Mount Telephone DP Box 10 Pairs Indoor Distribution Box With 10 Pair LSA Module
    • Wall Mount Telephone DP Box 10 Pairs Indoor Distribution Box With 10 Pair LSA Module
    • Wall Mount Telephone DP Box 10 Pairs Indoor Distribution Box With 10 Pair LSA Module
    • Wall Mount Telephone DP Box 10 Pairs Indoor Distribution Box With 10 Pair LSA Module
  • Wall Mount Telephone DP Box 10 Pairs Indoor Distribution Box With 10 Pair LSA Module

    Product Details:

    Place of Origin: ZHEJIANG, CHINA
    Brand Name: ANSHI
    Certification: ISO 90001, SGS, DAS, ROHS
    Model Number: AS-DB10

    Payment & Shipping Terms:

    Minimum Order Quantity: 100 pcs
    Price: Negotiable
    Packaging Details: Export Package
    Supply Ability: 5000 Pieces per Day
    Contact Now
    Detailed Product Description
    Product: 10 Paird Indoor Material: ABS
    Color: Cream Type: For 10 Pairs LSA-PLUS Module
    Size: 153*85*35mm Application: Telecommunication

    Wall Mount Telephone DP Box 10 Pairs Indoor Distribution Box with 10 pair LSA Module



    Application: Network
    Color: White
    Shape: Rectangle
    Usage: Electricity Transmission Project
    Type: Outdoor/Indoor
    Material:ABS


    1.Environment condition: -5-40 degree Celsius ;Relative humidity <85% (+30 degree Celsius);Atmospheric pressure: 70-106KPa

    2.The modules are compatible with KRONE LSA-PLUS modules.

    3.The design of contacts basing on the principle of airtight contacting makes a completely reliable connection between the contacts and wires

    4.Pulling-out force: tin bronze and silver plating (20-40 uinch), pulling-out force not less than 25N ;

    5.Internal diameter of connection wire: 0.4-0.6 mm

    6.The performance of anti-burn: PBT (UL94V-0)or anti-burn ABS (UL94V-0),Combustibility achieved GB/T 5169.7-1985 standard 7.Insulated resistance: under standard atmospheric pressure ,Insulated resistance no less than 1,000M ohm between the two disjunct connections ;

    8.Intermediate resistance between the reed terminators: no more than 7m ohm between intermediate reed under the standard examination condition ;

    9.Intermediate resistance: no more than 3m ohm under standard examination condition ;

    10.Dielectric strength: according to industry standard

    11.Specification: 30/ 50 / 100pairs, every specification has connection or disconnection types

    12.Life: durability 200 cycles




    Wall Mount Telephone DP Box 10 Pairs Indoor Distribution Box With 10 Pair LSA Module
    Wall Mount Telephone DP Box 10 Pairs Indoor Distribution Box With 10 Pair LSA Module
    Wall Mount Telephone DP Box 10 Pairs Indoor Distribution Box With 10 Pair LSA Module
