Silver Coated Krone LSA Module 8 Pairs , ABS / PBT Krone Connection Module For Telecom

Silver Coated Krone LSA Module 8 Pairs , ABS / PBT Krone Connection Module For Telecom

    • Silver Coated Krone LSA Module 8 Pairs , ABS / PBT Krone Connection Module For Telecom
    • Silver Coated Krone LSA Module 8 Pairs , ABS / PBT Krone Connection Module For Telecom
    • Silver Coated Krone LSA Module 8 Pairs , ABS / PBT Krone Connection Module For Telecom
  • Silver Coated Krone LSA Module 8 Pairs , ABS / PBT Krone Connection Module For Telecom

    Product Details:

    Place of Origin: ZHEJIANG, CHINA
    Brand Name: ANSHI
    Certification: ISO9001, CNACL, SGS, DAS
    Model Number: XL-014-8A

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000 pcs
    Price: Negotiable
    Packaging Details: CARTON:53*24*24CM
    Supply Ability: 10000 pcs per week
    Contact Now
    Detailed Product Description
    Material: ABS Or PBT Color: White/Grey
    Type: Connection Contact: Phosphor Bronze With Silver Coating
    Application: Telecommunication Protection Level: UL-94VO

    8 Pairs LSA-PLUS Krone Connection Module ABS or PBT UL-94VO



    Quick Detail:



    1. Material: PBT or ABS(UL94V-0)

    2. Contact: Phosphor Bronze

    3. Silver Plating: 0.5 um1.25 um5 um

    4. Can be installed on krone type stainless steel back mount frames

    5. Available with 50pair block tag and 100pair block tag.

    6. for mounting on MDF,racks,profile bracket,indoor and outdoor distribution box,cross connection cabinets.





    Applications:



    High speed LAN and WAN systems,used to connect the Telecom and Data wires with punch down tools.





    Specifications :



    Mechanical Performance Insertion force : 40~75N
    Pull Out Force : F≥25N(axial) F≥7.5N(radial)
    IDC Life : 200 times(20-26 AWG Solid wire) minimum
    Copper Conductor Diameter: Φ0.4~Φ0.8(mm)
    Environment Characteristic Storage Tempreture: 40 to 70°C
    Operating Temperature : 10 to 60°C
    Relative Humidity: 95%, noncondition
    Electrical Performance Insulation resistance: 1000 Mohms minimum
    Contact resistance :7 mohms maximum

    Dielectric intensity: AC 1000 Vrms 50Hz or 60Hz in 60s







    Silver Coated Krone LSA Module 8 Pairs , ABS / PBT Krone Connection Module For Telecom

    Silver Coated Krone LSA Module 8 Pairs , ABS / PBT Krone Connection Module For Telecom
