8 Pairs LSA Plus Module ABS / PBT UL - 94VO Disconnection Type Normal Closed

8 Pairs LSA Plus Module ABS / PBT UL - 94VO Disconnection Type Normal Closed

    • 8 Pairs LSA Plus Module ABS / PBT UL - 94VO Disconnection Type Normal Closed
    • 8 Pairs LSA Plus Module ABS / PBT UL - 94VO Disconnection Type Normal Closed
  • 8 Pairs LSA Plus Module ABS / PBT UL - 94VO Disconnection Type Normal Closed

    Product Details:

    Place of Origin: ZHEJIANG, CHINA
    Brand Name: ANSHI
    Certification: ISO9001, CNACL, SGS, DAS
    Model Number: XL-014-8A

    Payment & Shipping Terms:

    Minimum Order Quantity: 1000 pcs
    Price: Negotiable
    Packaging Details: CARTON:53*24*24CM
    Supply Ability: 10000 pcs per week
    Contact Now
    Detailed Product Description
    Material: ABS Or PBT Color: White/Grey
    Type: Disconnection (Normal Closed) Contact: Phosphor Bronze With Silver Coating
    Application: Telecommunication Protection Level: UL-94VO

    8 Pairs LSA-PLUS Krone Disconnection Module ABS or PBT UL-94VO



    Quick Detail:



    1. Material: PBT or ABS(UL94V-0)

    2. Contact: Phosphor Bronze

    3. Silver Plating: 0.5 um1.25 um5 um

    4. Can be installed on krone type stainless steel back mount frames

    5. Available with 50pair block tag and 100pair block tag.

    6. for mounting on MDF,racks,profile bracket,indoor and outdoor distribution box,cross connection cabinets.





    Description:



    We offer various modules in telecommunication application, the products includes 5pair LSA type connection and disconnection module, 8pair and 10 pair connection disconnection krone module,back mount function and profile function, switching module,10pair Earth connection module, high band modules, 3M type quick connect module, 25pair splicing module, 10pair STG module, Subscriber terminal block, 50pair and 100pair krone block tag, back-mount frames, and other related accessories like LSA patch cord for disconnection and switching modules,earth bar,dust cover,label holder and so on.



    The disconnection type CT module have provision of testing the electrical parameters of the exchange and distribution sides by insertion of test plug without actually disconnecting the jumper wire or the cable from the termination module.



    The module housing material we mainly offer with imported GE PBT and ABS(UL94V-0).Both material we will use new rall material but not recycling material(first recycling or second recycling).So we can offer good performance modules.You can get very cheap products in the market but they are mainly made of such recycling material PBT or ABS.





    Applications:



    High speed LAN and WAN systems,used to connect the Telecom and Data wires with punch down tools.





    Specifications :



    Mechanical Performance Insertion force : 40~75N
    Pull Out Force : F≥25N(axial) F≥7.5N(radial)
    IDC Life : 200 times(20-26 AWG Solid wire) minimum
    Copper Conductor Diameter: Φ0.4~Φ0.8(mm)
    Environment Characteristic Storage Tempreture: 40 to 70°C
    Operating Temperature : 10 to 60°C
    Relative Humidity: 95%, noncondition
    Electrical Performance Insulation resistance: 1000 Mohms minimum
    Contact resistance :7 mohms maximum

    Dielectric intensity: AC 1000 Vrms 50Hz or 60Hz in 60s







    8 Pairs LSA Plus Module ABS / PBT UL - 94VO Disconnection Type Normal Closed
